Dimensions

  • Maximum length

    4.000 mm

  • Maximum width

    1.400 mm

  • Overall height

    1.600 mm

  • Tara Weight

    880 kg

  • Suitable for

    Dangerous goods

  • Max load

    1500 kg

Specification

  • Finish

    Hot dip galvanised/ painted

  • Tow-Bar

    850 mm

  • Tow-Eye diameter

    Ø40 mm

  • Parking brake

    On front wheels, activated when in upright or downwards position

  • Type of steering

    Turntable steering

  • Tyres

    4

  • Wheel type (dia)

    3.00 D / 4.00 x 8

  • Maximum speed (unloaded)

    25 km/h

  • Cover

    Closed, 1 side sliding doors

  • Coupling

    S-P-S E-Hitch

Options

  • Coupling

    Ringfeder, Rockinger
