Dimensions

  • Maximum platform height

    3700 mm

  • Minimum platform height

    2400 mm

  • Overall width

    1930 mm

  • Overall length

    7467 mm

  • Tara weight

    1680 kg

  • Suitable for

    Passengers

Specification

  • Finish

    Hot dip galvanized and powder coated

  • Tow-Bar

    810 mm

  • Tow-Eye diameter

    Ø40 mm

  • Parking brake

    On front wheels, activated when in upright or downwards position

  • Type of steering

    Turntable steering

  • Position of steering

    Lower side of the stair

  • Tyres

    4

  • Wheel type (dia)

    3.00 D / 4.00 x 8 & 200*10-8

  • Maximum speed (unloaded)

    25 km/h

Options

  • Pedestrian control

    Solar powered

  • No touch

    No touch safety feature, only in combination with pedestrian control

  • Easy lift

    S-P-S Easy lifting system

  • LED light

    Illuminated stair flight

  • Basket

    Wheelchock basket

  • Cones storage

    Safety cones storage
