Dimensions

  • Maximum platform height

    5254 mm

  • Minimum platform height

    3400 mm

  • Overall width

    2768 mm

  • Overall length

    4870 mm

  • Tara Weight

    3000 kg

  • Suitable for

    Crew

Specification

  • Finish

    Hot dip galvanized and power coated

  • Tow-Bar

    800 mm

  • Tow-Eye diameter

    Ø40 mm

  • Parking brake

    On back wheels by hand brake

  • Type of steering

    Ackermann steering

  • Position of steering

    Higher side of the stair

  • Tyres

    4

  • Wheel type (dia)

    16 x 6 / 4.33

  • Maximum speed (unloaded)

    15 km/h

Options

  • Pedestrian control

    Solar powered. 5 km/h

  • No touch

    No touch safety feature, only in combination with pedestrian control

  • Easy lift

    S-P-S Easy lifting system

  • Basket

    Wheel chock basket

  • Cones storage

    Safety cones storage

  • Access light

    Green/ red light

  • Side coverage

    Side coverage by rubber flap
