Dimensions

  • Maximum length

    4416 mm

  • Maximum width

    3455 mm

  • Tara Weight

    1225 kg

  • Max load

    6800 kg

  • Suitable for

    LD1, LD3, LD4, P6

Specification

  • Finish

    Hot dip galvanised

  • Turntable deck

    No

  • Type of rollers

    Cargo rollers Ø89 mm, spring loaded

  • Tow-Bar

    1448 mm

  • Tow-Eye diameter

    Ø40 mm

  • Parking brake

    On front wheels, activated when in upright position

  • Type of steering

    Turntable steering, 2 wheel steering

  • Tyres

    8

  • Wheel type (dia)

    3.00 D / 15 x 4,5 - 8

  • Maximum speed (unloaded)

    25 km/h

  • Type of loading

    Narrow Edge Loading

  • Coupling

    S-P-S E-Hitch

Options

  • Coupling

    Ringfeder, Rockinger
