Dimensions

  • Maximum length

    5157 mm

  • Maximum width

    2650 mm

  • Tara Weight

    1375 kg

  • Max load

    4000 kg

  • Suitable for

    LD7, LD9, P1, P2, P6

Specification

  • Finish

    Hot dip galvanised

  • Turntable deck

    No

  • Type of rollers

    Cargo rollers Ø89 mm, spring loaded

  • Tow-Bar

    1836 mm

  • Tow-Eye diameter

    Ø40 mm

  • Parking brake

    On rear wheels, activated when in upright position

  • Type of steering

    Ackerman steering, 2 wheel steering

  • Tyres

    4

  • Wheel type (dia)

    365x160-220

  • Maximum speed (unloaded)

    25 km/h

  • Type of loading

    Narrow Edge Loading

  • Coupling

    S-P-S E-Hitch
