Dimensions

  • Maximum length

    4842 mm

  • Maximum width

    2723 mm

  • Tara Weight

    1250 kg

  • Max load

    6800 kg

  • Suitable for

    LD1, LD3, LD5, LD6, LD9, LD10, LD11, P1, P6, P9

Specification

  • Finish

    Hot dip galvanised

  • Turntable deck

    No

  • Type of rollers

    Cargo rollers Ø89 mm, bolted

  • Tow-Bar

    1000 mm

  • Tow-Eye diameter

    Ø40 mm

  • Parking brake

    On rear wheels, activated with separate handle

  • Type of steering

    Ackerman steering, 2 wheel steering

  • Tyres

    4

  • Wheel type (dia)

    365x160-220

  • Maximum speed (unloaded)

    25 km/h

  • Type of loading

    Wide Edge Loading

  • Coupling

    S-P-S E-Hitch

Options

  • Coupling

    Ringfeder, Rockinger
