Dimensions

  • Maximum length

    4566 mm

  • Maximum width

    3415 mm

  • Tara Weight

    1220 kg

  • Max load

    6800 kg

  • Suitable for

    LD1, LD3, LD4, LD6, LD8, LD9, LD11, LD29, MH1, PKC, FQA, PBJ, PAG, PMC

Specification

  • Finish

    Hot dip galvanised

  • Turntable deck

    No

  • Type of rollers

    Cargo rollers Ø89 mm, bolted

  • Tow-Bar

    1555 mm

  • Tow-Eye diameter

    Ø40 mm

  • Parking brake

    On front wheels, activated when in upwards position

  • Type of steering

    Ackerman steering, 2 wheel steering

  • Tyres

    8

  • Wheel type (dia)

    3.00 D / 15 x 4.5 - 8

  • Maximum speed (unloaded)

    25 km/h

  • Type of loading

    Narrow Edge Loading

  • Coupling

    S-P-S E-Hitch

Options

  • Coupling

    Ringfeder, Rockinger
