Dimensions

  • Maximum length

    4155 mm

  • Maximum width

    1800 mm

  • Tara Weight

    720 kg

  • Max load

    1680 kg

  • Suitable for

    LD1, LD3

Specification

  • Finish

    Hot dip galvanised

  • Turntable deck

    Yes

  • Type of rollers

    Cargo rollers Ø89 mm, spring loaded

  • Tow-Bar

    1530 mm

  • Tow-Eye diameter

    Ø50 mm

  • Parking brake

    By towbar, activated when in upwards position

  • Type of steering

    Steering rod, 4 wheel steering

  • Tyres

    4

  • Wheel type (dia)

    Ø360 x 75 x 270 Smooth profile mold on

  • Maximum speed (unloaded)

    25 km/h

  • Type of loading

    Narrow Edge Loading

  • Coupling

    SPS E-Hitch
