Dimensions

  • Maximum length

    3.682 mm

  • Maximum width

    1.760 mm

  • Tara Weight

    805 kg

  • Max load

    1.600 kg

  • Suitable for

    LD1, LD2, LD3

Specification

  • Finish

    Hot dip galvanised

  • Turntable deck

    Yes

  • Tow-Bar

    900 mm

  • Type of rollers

    Cargo rollers Ø89 mm, bolted

  • Tow-Eye diameter

    Ø40 mm

  • Parking brake

    On front wheels, activated when in upwards position

  • Type of steering

    Swivel pin steering, 4 wheel steering

  • Tyres

    4

  • Wheel type (dia)

    3.00 D / 4.00 x 8

  • Maximum speed (unloaded)

    25 km/h

  • Type of loading

    Narrow Edge Loading

  • Coupling

    S-P-S E-Hitch

Options

  • Coupling

    Ringfeder, Rockinger
