Dimensions

  • Maximum length

    3.957 mm

  • Maximum width

    1.370 mm

  • Overall height

    1.320 mm

  • Tara Weight

    500 kg

  • Suitable for

    Baggage

  • Max load

    1.000 kg

Specification

  • Finish

    Hot dip galvanised

  • Tow-Bar

    850 mm

  • Tow-Eye diameter

    Ø40 mm

  • Parking brake

    On front wheels, activated in upright or downwards position

  • Type of steering

    Turntable steering

  • Tyres

    4

  • Wheel type (dia)

    3.00 D / 4.00 x 8

  • Maximum speed (unloaded)

    25 km/h

  • Cover

    1 sides, canvas

  • Coupling

    SPS E-Hitch

Options

  • Coupling

    Ringfeder, Rockinger
